Wall Mount Pir Motion Sensor HC 7EN
PIR Motion Sensors & Switches

Wall Mount PIR Motion Sensor HC 7EN

Wall Mount Pir Motion Sensor HC 7EN


Motion sensor is a fully automatic indoor security/courtesy light controller capable of controlling up to 1200W. At night, the built in passive infrared (PIR) motion sensor turns on the connected lighting system when it detects motion in its coverage area. During the day, the built in photocell sensor saves electricity by deactivating the lights.

An adjustable time lets you select how long the light stays on after activation. The light  adjustment determine at what light level the lighting system will start operating when you set the motion sensor to automatic mode.

Features

  • Time  & LUX  Adjustment
  • Wall mount suitable
  • Stand alone Type
  • Save Electricity



Applications

  • Covered Parking
  • Stairways / Garage
  • Entrance / Corridors
  • Office / Toilets
  • ATM / Lockers / Pantry
  • Basements / Store / Lifts
  • And Many More!!!

Specifications
Detection Range

180°

Power Source 220V-240V/AC
Power Frequency 50/60Hz
Rated Load Max. 1200W (220-240V/AC)
Detection Distance 5-12m (<24℃) adjustable
Time Delay 10sec±3sec to 7min±2min(adjustable)
Ambient Light <3-2000LUX(adjustable)
Detection Motion Speed 0.6-1.5m/s
Installation Height 1.8-2.5m
Protection Class IP44
